12M 600daN Steel Utility Pole Gr65 Material for 55KV Power Distribution

Name: 12M 600daN Steel Utility Pole Gr65 Material for 55KV Power Distribution
Brand: MilkyWay
Price: 1 USD

12M 600daN Steel Utility Pole Gr65 Material for 55KV Power Distribution Manufactures

Brand Name : MilkyWay

Model Number : Steel Utility Pole

Certification : ISO9001/BV/

Place of Origin : China

MOQ : 1 pcs

Price : Negotiation

Payment Terms : T/T, L/C at sight

Supply Ability : 300pcs per day

Delivery Time : 20 working days after received your payment

Packaging Details : As customer request

Product Name : Steel Utility Pole

Application : Power Transmission

Surface treatment : hot dip galvanization

Lift time : 50 years

Galvanization standard : ASTM A 123

Material : Gr65

Warranty : 15 years

Dimenstion torlance : +- 2%

standard : ISO

Contact Now

12M 600daN Steel Utility Pole Gr65 Material for 55KV Power Distribution

Description:

Our Transmission Pole is designed for the high voltage power transmission and low voltage power transmission.
Designed and manufacutred for durability, corrosion resistance and visual appeal.

12M 600daN Steel Utility Pole Gr65 Material for 55KV Power Distribution

Specifications:

Material	Usually Q345B/A572 Q235B/A36 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-
Torlance of the dimension	+- 2%
Power	10 KV ~550 KV

Marks	Name plate through rivert or glue ,engrave ,emboss as per customer requirement
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required
Joint of Poles	Insert mode,inner flange mode,face to face joint mode
Design of pole	Against earthquake of 8 grade
Wind Speed	33 m /s
Minimum yield strength	355 mpa
Minimum ultimate tensile strength	490 mpa
Max ultimate tensile strength	620 mpa
Standard	ISO 9001
Length of per section	Within 14m once forming without slip joint

The information to inquiry or purchase
-Steel pole height and force
-Cross arm type and length,the position to install in the steel pole
-The method to fix the cross arm(use bolt to connect or use one or two template to weld in the steel pole to install the cross arm)
-Safety factor of the steel pole
-Wind speed
-Type of climbing rung
-Destination port
-Other.

12M 600daN Steel Utility Pole Gr65 Material for 55KV Power Distribution

Technical information-Cross Arm

12M 600daN Steel Utility Pole Gr65 Material for 55KV Power Distribution

The above listed is the most frequently used design,and is made from angel steel.And the cross arm will be fixed to the pole shaft connecting by bolts through the pre-drilling holes on both the cross arms and the pole shaft.If you have any other requirements on the design,material and connecting method for cross arm,pls contact us.
